LHD Dongfeng DFD4250GLFCEV2(Hydrogen Fuel Cell)
-
This van features a powerful permanent magnet synchronous motor with 360 kW peak power, ensuring excellent performance and efficient hydrogen fuel cell operation for extended driving range up to 400 km under full load.
-
Equipped with advanced Dongfeng Dana axles and multi-leaf spring suspension, the vehicle delivers superior stability, durability, and comfortable ride quality, even when carrying maximum load of 25 tons.
-
The spacious high-roof T719 cab includes laminated composite materials and ergonomic interior design, providing enhanced driver comfort with airbag shock-absorbing seats and a 7-inch infotainment system for convenience and safety.
-
Safety systems such as air brakes with ESC, self-adjusting components, wear alarms, and ADAS ensure reliable braking and accident prevention, complemented by a robust hydraulic power steering for precise handling.
-
Integrated hydrogen fuel cell technology paired with a large 140.96 kWh CATL battery and sizable hydrogen storage (1680 L) enables eco-friendly, zero-emission driving while maintaining strong power output and efficient energy usage.
This hydrogen fuel cell tractor is equipped with a permanent magnet synchronous motor delivering a peak power of 360 kW and torque up to 2500 Nm, offering strong performance. It features a dual-stack fuel cell system rated at 127 kW and a 140.96 kWh battery, achieving a full-load driving range of up to 400 km. Fitted with Dongfeng Dana axles, ESC, ADAS, air-suspension driver’s seat, and heating/cooling air conditioning, it ensures a safe and comfortable driving experience. With a high-roof cab, Beidou positioning, and T-BOX remote monitoring system, it is an ideal choice for efficient, eco-friendly, and intelligent transportation.
| 整车参数Basic Parameters | 总长
Total length( mm ) |
7830 | 动力系统Power system | 电机型号
Motor model |
TZ400XSTPG44 |
| 总宽
Overall width( mm ) |
2550 | 电机厂家
Motor manufacturer |
特百佳动力科技有限公司
TeBaijia Power Technology Co., Ltd. |
||
| 总高
Overall height( mm ) |
3820/3780 | 位置/燃油形式Location/Fuel Form | 中置/氢燃料电池Mid-mounted/hydrogen fuel cell | ||
| 轴距
Wheelbase( mm ) |
4050+1350 | 电机形式
Motor form |
永磁同步电机
Permanent magnet synchronous motor |
||
| 前悬/后悬
Front/rear suspension ( mm ) |
1530/900 | 电机额定/峰值功率Motor rated/peak power ( kw ) | 236/360 | ||
| 接近角/离去角
Approach angle/departure angle (°) |
20/45 | 额定/峰值扭矩Rated/peak torque(Nm) | 1400/2500 | ||
| 整备质量
Curb weight ( kg ) |
12250/11500 | 电池总容量
Total battery capacity ( kwh ) |
140.96kWh CATL | ||
| 最大总质量
Maximum total mass ( kg ) |
25000 | 续驶里程
Driving range (40 km /h constant speed method) |
400km (under full load condition) | ||
| 额定乘员数
Rated number of passengers (person) |
2 | 燃料电池额定/峰值功率
Fuel cell rated/peak power (kw) |
125/127 | ||
| 最高车速
Maximum speed ( km /h) |
85 | 氢瓶容积
Hydrogen bottle volume(L) |
8×210=1680L | ||
| 轮距（前/后）
Track (front/rear)(mm) |
2080/1860/1860 | 电堆厂家
Pile manufacturer |
锐唯
Chinese brand |
||
