LHD Dongfeng EQ1180EVJ(EV)
-
Equipped with a 324.576 kWh battery, offering a long driving range of up to 380 km for extended operational efficiency.
-
Powerful 200 kW electric motor delivers strong torque and performance for heavy-duty dump operations.
-
18-ton maximum gross weight allows for high payload capacity, ideal for construction and transport tasks.
-
Features hydraulic power steering, dual-circuit air brakes, and ABS for enhanced safety and control.
-
Comes with essential comfort and tech features like air conditioning, MP3 system, and T-BOX telematics.
The Dongfeng EQ1180EVJ is a mid-mounted, purely electric dump truck equipped with a permanent magnet synchronous motor delivering a peak power of 200 kW. It features a large 324.576 kWh battery from Anchi, providing a maximum driving range of up to 380 km. With a maximum gross weight of 18 tons, it offers strong loading and transport capabilities. The truck is equipped with hydraulic power steering, air conditioning, daytime running lights, T-BOX, and more, making it an ideal choice for urban and short-distance construction transport with high efficiency and environmental performance.
| 整车参数 Basic Parameters
|
总长（mm）
Total length( mm ) |
8350 | 动力系统参数 Power system | 电机型号
Motor model |
TZ220XY201 |
| 总宽（mm）
Overall width( mm ) |
2430 | 电机生产厂
Motor manufacturer |
精进电机
Jingjin Motor |
||
| 总高（mm）
Overall height( mm ) |
3400 | 位置/燃料形式
Location/Fuel Form |
中置/纯电动
Mounted/Purely Electric |
||
| 轴距（mm）
Wheelbase( mm ) |
4500 | 电机形式
Motor form |
永磁同步电机
Permanent magnet synchronous motor |
||
| 前悬/后悬（mm）
Front/rear suspension ( mm ) |
1500/2350 | 电机额定/峰值功率（kW）
Motor rated/peak power ( kw ) |
100/200 | ||
| 接近角/离去角（º）
Approach angle/departure angle (°) |
15/14 | 额定/峰值转矩（N.m）
Rated/peak torque(Nm) |
375/580 | ||
| 整备质量（kg）
Curb weight ( kg ) |
7500 | 电池总容量kWh/总电压V
Total battery capacity ( kwh )/Total Voltage V |
安驰324.576/579.6
Anchi 324.576 kWh / 579.6 V |
||
| 最大总质量（kg）
Maximum total mass ( kg ) |
18000 | 续驶里程（40km/h匀速法）
Driving range (40 km /h constant speed method) |
380km | ||
| 额定乘员数 （人）
Rated number of passengers (person) |
2，3 | ||||
| 最高车速（km/h）
Maximum speed ( km /h) |
85 | ||||
| 轮距（前/后）（mm）
Track (front/rear)(mm) |
1930/1830 | ||||
