LHD Dongfeng EQ6105CT5D (Diesel)
-
Euro V-Compliant Diesel Power
Equipped with a robust 213kW Cummins ISL290 engine delivering 1055N·m torque, this bus ensures strong performance while meeting stringent Euro V emission standards for cleaner urban operation. -
Enhanced Passenger Accessibility
Features a low 360mm entry step, wheelchair-friendly zones, and flip-out steps to accommodate elderly and disabled passengers seamlessly. -
Advanced Safety Systems
Includes dual-circuit pneumatic brakes (functional at -45°C), 6-camera surveillance, and anti-pinch doors for comprehensive passenger and driver protection. -
All-Weather Comfort
Roof-mounted AC, heated driver seat, PTC heating, and insulated sliding windows ensure comfort in extreme climates, supported by cold-resistant components. -
Smart Transit Features
Integrated LED route displays, USB charging ports, and a 32GB multi-camera recording system modernize the passenger experience and operational monitoring.
This 10.49-meter urban transit bus features a rear-mounted Dongfeng Cummins ISL290 50 diesel engine (213kW/1055N·m) compliant with Euro V emissions. With a capacity for 85 passengers, it combines a semi-load-bearing body with air suspension (ECAS-controlled) and disc brakes for smooth operation.
Key highlights include:
-
Accessibility: 360mm low-entry step, wheelchair area, and flip-step flooring
-
Safety: Dual-circuit pneumatic brakes (-45° anti-ice), 6-camera surveillance, and anti-pinch doors
-
Comfort: Roof-mounted AC, heated driver seat, and insulated side windows
-
Smart Features: LED route displays, USB charging ports, and multi-channel video recording
Ideal for cold climates with electric preheating and PTC heating, it’s built for reliability with copper radiators and centralized lubrication.
| 整车参数
Vehicle parameters |
总长（mm）
Total length (mm) |
10490 | 发动机参数
Engine parameters |
发动机型号
Engine model |
ISL290 50 |
| 总宽（mm）
Total width (mm) |
2500 | ||||
| 总高（mm）
Total height (mm) |
3340 | 发动机生产厂
Engine manufacturing plant |
东风康明斯
Dongfeng Cummins |
||
| 车厢内高（mm）
Height inside the carriage (mm) |
2280 | 位置/燃油
Location/Fuel |
后置/柴油
Rear/Diesel |
||
| 轴距（mm）
Wheelbase (mm) |
5000 | 发动机型式
engine type |
直列 六缸
Inline six cylinder |
||
| 前悬/后悬（mm）
Front/rear suspension (mm) |
2380/3110 | 最大功率（kw/r/min）
Maximum power (kw/r/min) |
213/2100 | ||
| 接近角/离去角（º）
Approach angle/departure angle (º) |
9/8 | 最大扭矩（N.m/r/min）
Maximum torque (N.m/r/min) |
1055/1400 | ||
| 一级踏步高（mm）
First level step height (mm) |
360 | 排量(L)
Displacement (L) |
8.9 | ||
| 厂定最大总质量（kg）
Factory determined maximum total mass (kg) |
16000 | 排放标准
Emission standard |
欧 V
Euro V |
||
| 额定乘员数 （人）
Rated number of passengers (person) |
85/20-37 | ||||
| 最高车速（km/h）
Maximum speed (km/h) |
69(限速)
69 (speed limit) |
||||
| 行李仓容积（m3）
Luggage compartment capacity (m3) |
— | ||||
| 轮距（mm）
Track width (mm) |
2060/1860 | ||||
