LHD Dongfeng EQS180XXYTQBEV1 (EV)
-
Zero Emissions & Eco-Friendly
Powered by a pure electric drivetrain, this dump truck eliminates exhaust pollution, making it ideal for sustainable urban construction and green logistics. -
High-Performance Electric Motor
The 200kW permanent magnet synchronous motor delivers strong torque (580Nm) for excellent load-carrying capacity and uphill performance. -
Long Battery Range
With a 342.5kWh battery, it achieves up to 380km per charge (at 40km/h), ensuring extended work cycles without frequent recharging. -
Durable & Heavy-Duty Design
Features a double-layer reinforced chassis, 9T rear axle, and robust leaf spring suspension for reliable operation in tough construction environments. -
Smart & Safe Features
Includes ABS brakes, low-speed warning alerts, T-BOX telematics, and hydraulic power steering for enhanced safety and operational efficiency.
The Dongfeng EQS180XXYTQBEV1 is an efficient and eco-friendly electric dump truck with a total length of 8,460 mm and a maximum gross weight of 18 tons. It is powered by a Jingjin Motor permanent magnet synchronous motor (peak power: 200 kW, torque: 580 N·m) and equipped with an Anchi 342.576 kWh high-capacity battery, delivering a 380 km range (at 40 km/h constant speed).
The truck features a double-layer reinforced chassis, Heze axles, a 4E120 gearbox, and an air brake system with ABS. Standard configurations include PTC heating, cab air conditioning, electric windows, and a left-hand drive half-cab design. Ideal for urban construction and waste transport, it combines high performance with zero emissions.
| 整车参数 Basic Parameters
|
总长（mm）
Total length( mm ) |
8460 | 动力系统参数 Power system | 电机型号
Motor model |
TZ220XY201 |
| 总宽（mm）
Overall width( mm ) |
2550 | 电机生产厂
Motor manufacturer |
精进电机
Jingjin Motor |
||
| 总高（mm）
Overall height( mm ) |
3850,3950 | 位置/燃料形式
Location/Fuel Form |
中置/纯电动
Mounted/Purely Electric |
||
| 轴距（mm）
Wheelbase( mm ) |
4500 | 电机形式
Motor form |
永磁同步电机
Permanent magnet synchronous motor |
||
| 前悬/后悬（mm）
Front/rear suspension ( mm ) |
1500/2460 | 电机额定/峰值功率（kW）
Motor rated/peak power ( kw ) |
100/200 | ||
| 接近角/离去角（º）
Approach angle/departure angle (°) |
15/11 | 额定/峰值转矩（N.m）
Rated/peak torque(Nm) |
375/580 | ||
| 整备质量（kg）
Curb weight ( kg ) |
9340 | 电池总容量kWh/总电压V
Total battery capacity ( kwh )/Total Voltage V |
安驰342.576/579.6
Anchi 342.576 kWh / 579.6 V |
||
| 最大总质量（kg）
Maximum total mass ( kg ) |
18000 | 续驶里程（40km/h匀速法）
Driving range (40 km /h constant speed method) |
380km | ||
| 额定乘员数 （人）
Rated number of passengers (person) |
2，3 | ||||
| 最高车速（km/h）
Maximum speed ( km /h) |
89 | ||||
| 轮距（前/后）（mm）
Track (front/rear)(mm) |
1930/1830 | ||||
